BioSense Clinical Continuous Wearable

Sub-microwatt 4-layer rigid-flex biometric wearable monitoring SpO2, heart-rate variability, and skin conductance with 14-day continuous battery life.

Nordic nRF5340 Dual-Core4-Layer Rigid-FlexFreeRTOSIPC Class 3

BioSense Clinical Continuous Wearable — hardware engineered by Safe Switching

VERIFIED HARDWARE SPECIFICATIONS & ARCHITECTURE

LAYER COUNT

4-Layer Rigid-Flex

MCU PLATFORM

Nordic nRF5340 Dual-Core

PROTOCOL / BUS

BLE 5.3 Direction Finding

STANDARD

IPC-A-610 Class 3

BOM HIGHLIGHTS:

Analog Devices MAX86176Nordic nRF5340Custom Ceramic Antenna

Bio-Compatible Wearable Engineering Designed for continuous clinical diagnostics, this medical-grade wearable leverages an ultra-compact rigid-flex substrate contouring around the wrist.

Technical Specifications * Processor: Dual-core Nordic nRF5340 running Zephyr RTOS. * Optical Engine: Multi-wavelength optical photoplethysmogram (PPG) analog front-end with ambient light cancellation. * Power Management: Custom PMIC circuit with sub-1.2µA shelf standby current and wireless Qi inductive charging coil.
